Merchanical Interlocking Contactor 3TD series

SPECIFICATION

Type	Rated thermal current(A)	Rated operation current(A)		Controllable power of motor(KW)
				AC-3		AC-4
		380V	660V	380V	660V	380V	660V
3TD40	20	9	7	4	5.5	1.4	2.4
3TD41	20	12	8.5	5.5	7.5	1.9	3.3
3TD42	30	16	12.5	7.5	11	3.5	6
3TD43	30	22	16.5	10	15	4	6.6
3TD44	55	32	24	15	22	7.5	13
3TD45	55	38	24	18.5	22	9	15.5
3TD46	80	45	40	22	37	12	20.8
3TD47	80	63	60	30	55	14	24.3
3TD48	100	75	60	37	55	17	29.5
3TD49	100	85	80	45	75	21	36
3TD50	160	110	95	55	90	27	46.9
3TD51	160	140	120	75	110	35	60
3TD52	200	170	160	90	150	38	66
3TD53	210	205	165	110	160	50	86
3TD54	300	250	230	132	220	58	100
3TD55	300	300	260	160	250	66	114
