Photo Control PH-116
| Ratec Voltage: |
120V.230V(±5%) |
| Rated Frequency: |
50/60Hz |
| Rated Current: |
6A |
| Light Level: |
ON:<20Lux OFF:<80Lux |
| Acting Time: |
ON:<2′OFF:<2′ |
| Electrical Life: |
>6500Circles | |
Installation
The controller works according to the scene illumination.
1.It can not be illuminated by the simulative light of 50lux or more.
2.It can not be installed in the shadow of 20lux or less (daytime).
3.The wire of the controller cannot be mis-connected (red wire/load,white wire/controlling wire,black wire/neutral wire).
|
