INDEX TYPE |
T-50-A |
T-50-B |
T-50-C |
|
DC VOLTAGE |
5V |
12V |
-5V |
5V |
12V |
-12V |
5V |
15V |
-15V |
|
VOLTAGE ADJ.RANGE |
+10%--5% |
|
|
+10%--5% |
|
|
+10%--5% |
|
|
|
VOLTAGE TOLERANCE |
±2% |
±5% |
±5% |
±2% |
±5% |
±5% |
±2% |
±5% |
±5% |
|
RATED CURRENT |
7A |
1A |
1A |
5A |
1A |
1A |
4A |
1A |
1A |
|
CURRENT RANGE |
0.6-7A |
0.2-1A |
0.2-1A |
0.6-5A |
0.2-1A |
0.2-1A |
0.6-4A |
0.2-1A |
0.2-1A |
|
RATED POWER |
52W |
49W |
50W |
|
EFFICIENCY(Typ.) |
66% |
69% |
71W |
|
RIPPLE&NOISE(MAX.) |
100mvp-p |
100mvp-p |
100mvp-p |
100mvp-p |
100mvp-p |
100mvp-p |
100mvp-p |
100mvp-p |
100mvp-p |
|
LINE REGULATION |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
±0.5% |
±1% |
±1% |
|
LOAD REGULATION |
±1% |
±4% |
±4% |
±1% |
±4% |
±4% |
±1% |
±4% |
±4% |
|
VOLTAGE RANGE |
85-132VAC/170-264VAC 47-63Hz 240-370VDC |
|
AC CURRENT |
1.3/115VAC 0.65A/230VAC |
|
INRUSH CURRENT(MAX.) |
cold inrushed current 18A/115VAC 36A/230VAC |
|
LEAKAGE CURRENT |
<0.5mA/240VAC |
|
OVERLOAD PROTECTION |
105-150% type ：current limitation ，auto recovery |
|
OVERVOLTAGE PROTECTION |
-- |
|
OVERTEMPERATURE PROTECTION |
-- |
|
TEMP.COEFFICIENT |
±0.03%／℃(0-50℃) |
|
SETUP.RISE,HOLD TIME |
200ms 50ms 20ms /230VAC |
|
WITHSTAND VOLTAG |
I/P-O/P:3KVACI/P-FG:1.5KVACO/P-FG:0.5KVAC |
|
ISOLATED RESISTOR |
I/P-O/P:3KVACI/P-FG:1.5KVACO/P-FG:0.5KVAC |
|
STORAGE TEMP.HUMIDITY |
0-50℃@100%,-10℃@80%,60℃@60%,20%-90%RH |
|
WEIGHT |
0.45Kg |
|
SAFETY STANDARDS |
UL1012 |
|
EMC |
CLSPT22(EN55022)CLASSB,IEC801-2,3,4.IEC555-2. |
|
Note：
1.All parameters NOT specially mentioned are measured at 230VAC input ,rated load and 25 of ambient temperature.
2.Tolerance:includes set up tolerance,line regulation and load regulation
3.Ripple&noise are measured at 20MHZ of bandwidth by using a 12 twisted pair-wire terminated with a 0.1uf&47uf parallel capacitor.
4.line regulation:min&max voltage of the rated load.
5.load regulation:load from 0 to 100%. |
