Technical data:
Material:
● PE, Polyethylene, good pliability, transparence, extensibility, resist dissolve, radiation . Working Termperature: - 40℃ to 65℃, short time is 80℃.
● Brass, screw is Iron plated zinc.
● Plastic setting Color is Blue color as standard
● Voltage: 250 - 450V
● Remark: We can according to customer require supply different size, such as, different length, width, hole diameter etc.
● PE, 聚乙烯, 良好的柔韧性、透明度、延伸性、 抗溶性, 耐辐射, 工作温度: - 40℃ to 65℃, 瞬时可达: 80℃
● 黄铜, 螺丝铁质表面镀锌
● 适用电压范围: 250 - 450V
● 底座颜色: 蓝色,特殊颜色欢迎订做
● 备注：我司还可以按客户的要求提供不同长度、宽度、孔径、孔数
|
Item no. |
Spec. |
L1 |
L2 |
H |
W |
ø |
screw size |
Plastic setting |
|
w×h-hole |
mm |
|
SP031-01 |
6×9-8 |
86 |
58 |
43 |
11.5 |
4.3 |
M4×7 |
PE |
|
SP031-02 |
6×9-10 |
86 |
70 |
43 |
11.5 |
4.3 |
M4×7 |
PE |
|
SP031-03 |
6×9-12 |
86 |
82.5 |
43 |
11.5 |
4.3 |
M4×7 |
PE |
|
SP031-04 |
6×9-14 |
86 |
94 |
43 |
11.5 |
4.3 |
M4×7 |
PE |
|
SP031-05 |
6×9-16 |
86 |
107.6 |
43 |
11.5 |
4.3 |
M4×7 |
PE |
|
SP031-06 |
6×9-18 |
86 |
120 |
43 |
11.5 |
4.3 |
M4×7 |
PE |
|
SP031-07 |
6×9-20 |
86 |
132 |
43 |
11.5 |
4.3 |
M4×7 |
PE |
|
SP031-08 |
6×9-22 |
86 |
144.4 |
43 |
11.5 |
4.3 |
M4×7 |
PE | |
