Technical data:
Material:
● PA, Polyamide 6/6, 94V-2 grade. inflaming retarding, good resist dissolve, good bounce impact force,Working Termperature: - 35℃ to 120℃, short time is 140℃.
● Brass, screw is brass too, surface plated brass.
● Voltage: 250 - 450V
● Color: Blue & white color
● PA, 尼龙 6/6, 防火等级:94V-2. 阻燃、 抗溶性、抗冲击力好, 工作温度: - 35℃ to 120℃, 瞬时可达140℃
● 黄铜表面镀铜，螺丝铜质表面镀铜
● 适用电压范围: 250 - 450V
● 颜色: 蓝白色
|
Item no. |
Spec. |
L1 |
L2 |
W |
H |
ø1 |
ø2 |
screw size |
|
mm |
|
SP027-01 |
50mm2 |
49 |
33 |
31.5 |
60 |
20 x 10 |
3 |
\ |
|
SP027-02 |
70mm2 |
50 |
42 |
37.8 |
70 |
25 x 12 |
3 |
\ |
|
SP027-03 |
100mm2 |
70 |
56 |
44.8 |
83 |
26 x 14.5 |
4.5 |
\ |
|
SP027-04 |
160mm2 |
105 |
82 |
64.4 |
110 |
33 x 20 |
4.5 |
\ | |
