| CP Catena Current Mutual Ware |
 |
Name: CP Catena current mutual ware
Model: CP45/14
Key Specifications & Feature
Secondary current 5A
Frequency 50/60Hz
Rated current 720v
Security factor : FS-5
High voltage test 4kv, 50Hz,1 min
Weight:200-250gr |
|
Rated current(A) Primary/Secondary |
30/5A 40/5A |
50/5A |
60/5A |
75/5A 80/5A |
100/5A |
|
Accuracy class |
3 |
1.0 |
1.0 |
1.0 |
1.0 |
|
Rated Burden(VA) |
1 |
1.5 |
2.5 |
2.5 |
2.5 |  |
|
