Technical data:
Material:
● PA, Polyamide 6/6, 94V-2 grade. inflaming retarding, good resist dissolve, good bounce impact force, Working Termperature: - 35℃ to 125℃, short time is 140℃.
● Brass, screw is Iron plated zinc.
● Voltage: 250 - 450V
● Color: Natural color as standard
● PA, 尼龙 6/6, 防火等级:94V-2. 阻燃、 抗溶性、抗冲击力好, 工作温度: - 35℃ to 120℃, 瞬时可达140℃
● 黄铜, 螺丝铁质表面镀锌
● 适用电压范围: 250 - 450V
● 颜色: 产品本色
|
Item no. |
Spec. |
L |
W1 |
W2 |
H |
ø |
screw size |
material |
|
mm |
|
SP011-01 |
3A 4mm2 |
93.5 |
32 |
5.5 |
11 |
2.8 |
M2.5×4 |
PA |
|
SP011-02 |
6A 6mm2 |
115 |
32 |
6 |
13 |
3.2 |
M3.0×4.5 |
PA |
|
SP011-03 |
10A 10mm2 |
132 |
36.8 |
7 |
15 |
4.2 |
M3.0×6 |
PA |
|
SP011-04 |
16A 12mm2 |
140.5 |
40 |
7.5 |
17 |
4.4 |
M3.5×7 |
PA | |
