Technical data:
Material:
● PP, Polypropylene, inflaming retarding, low transparency, low rigidity, good bounce impact force.Working Termperature: - 30℃to 90℃, short time is 110℃
● PA, Polyamide 6/6, 94V-2 grade. Inflaming retarding, good resist dissolve, good bounce impact force, Working Termperature: - 35℃ to 120℃, short time is 140℃.
● Brass, screw is Iron plated zinc.
● Voltage: 250 - 450V
● Color: blue color as standard
● PP, 聚丙烯, 阻燃、低透明度、低刚性, 抗冲击力好, 工作温度: - 30℃ to 90℃, 瞬时可达 110℃
● PA, 尼龙 6/6, 防火等级:94V-2. 阻燃、 抗溶性、抗冲击力好,工作温度: - 35℃ to 120℃, 瞬时可达140℃
● 黄铜, 螺丝铁质,表面镀锌
● 适用电压范围: 250 - 450V
● 颜色: 蓝色，特殊颜色欢迎订做
|
Item no. |
Spec. |
L |
W1 |
W2 |
H1 |
H2 |
ø |
E1 |
E2 |
screw size |
material |
|
mm |
|
SP009-01 |
15A 12mm2 |
117 |
24.5 |
17 |
14.5 |
8 |
3.3 |
9.8 |
7.8 |
M3.0×6 |
PP PA |
|
SP009-02 |
20A 14mm2 |
128.5 |
26.5 |
18.5 |
16 |
9 |
4.2 |
11 |
9.4 |
M3.0×6 |
PP PA |
|
SP009-03 |
30A 16mm2 |
157 |
31.4 |
22 |
18.7 |
11.4 |
5.3 |
13.5 |
11.5 |
M4.0×7 |
PP PA | |
