TERMINAL CONNECTOR(COMPRESSION TYPE,A TYPE)

| Type |
Suitable conductor(mm) |
Dimensions(mm) |
40.5Weight(kg)
|
| Suitable conductor |
Outer dia.(mm)
|
b |
s |
D |
L |
a |
Ø |
| SY-35/6A |
LGJ-35/6A |
8.16 |
30 |
8 |
16 |
60 |
65 |
9.5 |
0.07 |
| SY-50/8A |
LGJ-50/8A |
9.60 |
30 |
8 |
18 |
60 |
65 |
11.0 |
0.06 |
| SY-70/10A |
LGJ-70/10A |
11.40 |
40 |
8 |
22 |
70 |
65 |
13.0 |
0.12 |
| SY-95/15A |
LGJ-95/15A |
13.61 |
40 |
8 |
26 |
80 |
65 |
15.0 |
0.16 |
| SY-20/7A |
LGJ-20/7A |
14.50 |
50 |
10 |
26 |
80 |
85 |
16.0 |
0.21 |
| SY-150/8A |
LGJ-150/8A |
16.00 |
50 |
10 |
30 |
90 |
85 |
17.5 |
0.28 |
| SY-150/20A |
LGJ-150/20A |
16.67 |
50 |
10 |
30 |
90 |
85 |
18.0 |
0.28 |
| SY-185/10A |
LGJ-185/10A |
18.00 |
50 |
10 |
32 |
90 |
85 |
19.5 |
0.33 |
| SY-185/25A |
LGJ-185/25A |
18.90 |
50 |
10 |
32 |
90 |
85 |
20.5 |
0.33 |
| SY-210/10A |
LGJ-210/10A |
19.00 |
50 |
10 |
34 |
100 |
85 |
20.5 |
0.44 |
| SY-210/25A |
LGJ-210/25A |
19.98 |
50 |
10 |
34 |
100 |
85 |
21.5 |
0.44 |
| SY-240/30A |
LGJ-240/30A |
21.60 |
50 |
12 |
36 |
100 |
85 |
23.0 |
0.54 |
| SY-300/15A |
LGJ-300/15A |
23.01 |
63 |
12 |
40 |
110 |
105 |
24.5 |
0.61 |
| SY-300/20A |
LGJ-300/20A |
23.43 |
63 |
12 |
40 |
110 |
105 |
25.0 |
0.61 |
| SY-300/25A |
LGJ-300/25A |
23.76 |
63 |
12 |
40 |
110 |
105 |
25.5 |
0.61 |
| SY-300/40A |
LGJ-300/40A |
23.94 |
63 |
12 |
40 |
110 |
105 |
25.5 |
0.61 |
| SY-400/20A |
LGJ-400/20A |
26.91 |
63 |
13 |
45 |
120 |
105 |
28.5 |
0.69 |
| SY-400/25A |
LGJ-400/25A |
26.64 |
63 |
13 |
45 |
120 |
105 |
28.5 |
0.69 |
| SY-400/35A |
LGJ-400/35A |
26.82 |
63 |
13 |
45 |
120 |
105 |
28.5 |
0.69 |
| SY-400/50A |
LGJ-400/50A |
27.63 |
63 |
13 |
45 |
120 |
105 |
29.5 |
0.69 |
| SY-500/35A |
LGJ-500/35A |
30.00 |
80 |
16 |
52 |
130 |
85 |
31.5 |
0.69 |
| SY-500/45A |
LGJ-500/45A |
30.00 |
80 |
16 |
52 |
130 |
85 |
31.5 |
0.69 |
| SY-500/65A |
LGJ-500/65A |
30.96 |
80 |
16 |
52 |
130 |
85 |
32.5 |
0.69 |
| SY-630/45A |
LGJ-630/45A |
33.60 |
100 |
20 |
60 |
150 |
105 |
35.5 |
1.20 |
| SY-630/55A |
LGJ-630/55A |
34.32 |
100 |
20 |
60 |
150 |
105 |
36.0 |
1.20 |
| SY-630/80A |
LGJ-630/80A |
34.82 |
100 |
20 |
60 |
150 |
105 |
36.0 |
1.20 |
| SY-800/55A |
LGJ-800/55A |
38.40 |
125 |
22 |
65 |
170 |
130 |
36.5 |
2.16 |
| SY-800/70A |
LGJ-800/70A |
38.58 |
125 |
22 |
65 |
170 |
130 |
40.0 |
2.14 |
| SY-800/100A |
LGJ-800/100A |
38.98 |
125 |
22 |
65 |
170 |
130 |
40.5 |
2.14 |
|
