15Amp, 125Volt, 2P, 3W, Decora plus Duplex receptacle, Straight Blade, Self - Grounding,All screws backed Out contractor Pack, quick-wire Push- In & Side Wired, Steel Strap, color is optional.
Product Features:
Ground: Self-Grounding
Feature: All Screws Backed Out Contractor Pack
Amperage: 15A
Voltage: 120V AC
NEMA: 5-15R
Pole: 2
Wire: 3
Termination: Quick-wire Push-In & Side
Face Material: Thermoplastic
Body Material: Thermoplastic
Strap material: Steel
Standard Color: White, Ivory, Black, Almond, Grey, Brown
Standard & Certification; UL/CUL
* UL&CUL No.E311193
* Meet UL498 Standard
* Wraparound design is molded of highimpact, chemical-resistantnylon
* Heavy-duty wraparound steel yoke
* Terminal screws: brass combination Phillips / slotted / Robert-sonbinding head accepts up to #10 wire
* Easily accessible break-off tab for two-circuit wiring
* Self-grounding strap for quick installation
* Back wiring: eight wiring pockets for convenient feed-thru wiring, clamp-type terminals accepts up to #10 wire
|
