¢ñ. Main Technical Indexes
    1.Service Conditions:Altitude:under 2000m
      Ambient temperature:-25¡æ¡«50¡æ
      Relative humidity:¡Ü90% at 25¡æ;¡Ü50% at 40¡æ
      Declining degree of installation:¡Ü5¡æ
    2.Rated Voltage:400V, 50Hz
    3.Rated Output:9, 15, 18, 24, 30, 36, 48, 60, 80, 96, 120kvar(Asfor corre sponding transformer capacity for compensation, see table 1)
    4.Rang of Working Voltage:0.85¡«1.10 times rated voltage
    5.Max.permissible current:1.3 times rated current.
    6.Number of Circuits Controlled:3 channels, 4 channels, 8 channels.
    7.Switching Time:0¡«90s per time, continual digit type and adjustable. It has been set at 30s per time in factory.
    8.Working Way:Automatic and continual operation. The capacitor applies the switching way of constant volume cycle:First throw in and first throw out, later throw in and later throw out, which can prolong the service life of the capacitor.
    9.Cos £¦#118alue retains above 0.95 when load changes within 5¡«100%.
    10.The installation is used indoors and its shell is designed wall build-up type.
    11.Accord with JB/T7113-1993 Low-Voltage shunt Capacitor Installation.

¢ò. Application
¡¡¡¡Discharge in ultra short moment can produce strong pulse current.It can be widely used in new technologies like sunge voltage generator,surge curtent generator,magnetizer,plasma processing,laser,ets,The products meet JB/T8168-1999 Pulse Capacitor and DC Capactior Standard.
