Name |
59 Moving Coil instrument DC Ammeter 59 磁电系（动圈式）直流电流表 |
| Model |
> Ammeter > 59 Series |
| Type |
59C2 DC A |
Accuracy: class 2.5
Specification: 50uA 100uA 150uA 500uA 1mA 2mA 5mA 10mA 20mA 30mA 50mA 75mA 100mA 150mA 200mA 250mA 300mA 500mA 1A 2A 3A 7.5A 10A 20A 30A 50A , if measuring ranges over 50A, meters can be connected external shunt with 50mV,60mV or 75mV | |
| |
|
|
|
