Electrical Items >> Thyristor and Rectifier >> ZX Disc Rotation Rectifier and Thyristor



转整流管/旋转晶闸管 Rotation Rectifiers/Rotation Thyristors
 特征  Features
 ■ 可在较大离心力作用下工作  ■ Can Be Worked Under Grater Centrifugal Force
 应用  Applications
 ■ 使用于旋转励磁发电机(电动机)  ■ Specinl Use For Rotation Excitation Dynamotor(Electromotor)
旋转整流管Rotation Rectifiers (ZX Disc model)
型号
Type
IF(AV)
VFM
VRRM
IRRm
IFSM
Tjm
Rjc
承受离心加速度
(A)
(V)
(mA)
(mA)
(kA)
(℃)
(℃/W)
正常长期工作(g)
超速(g)
ZX40
40
≤1.35
100~1600
≤3
0.40
150
0.80
1250
2500
ZX100
100
≤1.6
100~2800
≤7
≤1.5
150
0.80
1250
2500
ZX200
200
≤1.6
100~2800
≤14
≤3.0
150
0.80
1250
2500
ZX300
300
≤1.6
100~2800
≤21
≤4.5
150
0.80
1250
2500
ZX500
500
≤1.6
100~2800
≤35
≤7.5
150
0.80
5000
5500

旋转晶闸管Rotation Thyristors (KX Disc model)
型号
Type
IF(AV)
VTM
VRRM/VDRM
IRRM/IDRM
ITSM
Tjm

IGT/VGT

IH
dv/dt
Rjc
承受离心加速度
(A)
(V)
(mA)
(mA)
(kA)
(℃)
(mA/V)
(mA)
(V/μS)
(℃/W)
正常长期工作(g)
超速(g)
KX40
40
≤1.6
50~1600
≤10
1
125
150/2.5
≤50
≥100
0.46
1250
2500(4小时)
KX100
100
≤1.6
50~2000
≤20
2.2
125
150/3.0
≤100
≥100
0.25
1250
2500(4小时)
KX200
200
≤2.0
50~2000
≤30
2.5
125
250/3.0
≤200
≥100
0.11
1250
2500(4小时)
KX300
300
≤1.85
75~3000
≤30
3.8
125
250/3.5
≤200
≥100
0.073
1250
2500(4小时)
KX500
500
≤2.7
75~3000
≤50
6.3
125
300/3.5
≤200
≥100
0.073
5000
5500(5小时
